AUTOSTEM GENERATION 1 & 2

AutoStem offers the highest energy pyrotechnic blasting cartridge world-over, having introduced the world's first self-stemming cartridge in 2013 with AutoStem Generation 1.​ We introduced the AutoStem Generation 2 in 2014 as the world's first 43mm pyrotechnic cartridge range with dual self-stemming capability and available in power charges up to 300g.​



The AutoStem range of pyrotechnic cartridges are now available in sizes between 32mm - 87mm and power charges from 20g-2kg making AutoStem pyrotechnic cartridges the largest range of pyrotechnic blasting cartridges available world-over.

Still a product favorite world-wide, the AutoStem range of pyrotechnic products offer numerous advantages over other blasting methods in sensitive locations and for specific blasting needs.

All products are accredited internationally and recognized as 1,4s UN 0323 / UN 0432 / UN 0349

The original AutoStem Cartridge - AutoStem 1

  • Cartridges available in diameter of 32mm (1.26 inch)

  • Suitable for use in a borehole of maximum 34mm diameter (1.34 inch)

  • world's first drop-and-go cartridge, requiring no stemming or tamping effort

Product sizes available:

  • 20g   (120 per box, NEQ: 2.4kg) - cartridge length: 220mm

  • 40g   (100 per box, NEQ: 4.0kg) - cartridge length: 270mm

  • 60g   (90 per box, NEQ: 5.4kg)   - cartridge length: 320mm

  • 80g   (80 per box, NEQ: 6.4 kg)  - cartridge length: 370mm

  • 100g (60 per box, NEQ: 6.0kg)   - cartridge length: 420mm

Suitable for:

  • Civil blasting in built up areas

  • Oversize management in quarry pits

  • Slyping, footwall and hanging wall clearing

  • Concrete breaking

  • Trenching

  • Residential blasting

Boosters available in cartridges sizes of 60g and 100g

Standard Cartridge assembled with ignitor

Optional assembly to accommodate a detonator/shocktube initiation

Product is fully accredited in all major global markets including:

  • CE mark of approval (European Union);

  • USA (Department of Transport)

  • Canada (Ministry of Natural Resources)

  • South Africa (SAPS) and continental Africa

  • Australia (Chamber of Mines)

  • India (Explosive regulator)

  • Continental South America (Brazil, Chile, Mexico)

AutoStem Generation 1 - 32mm cartridge for a 34mm hole

The first dual stemming blasting cartridge - AutoStem 2

  • Cartridges available in diameter of 43mm (1.69 inch)

  • Suitable for use in a borehole up to 50mm diameter (2.0 inch)

  • Dual-stemming technology, product will function even in fractured ground

Product sizes available:

  • 150g (52 per box, NEQ: 7.8kg) - cartridge length: 242mm

  • 200g (42 per box, NEQ: 8.4kg) - cartridge length: 292mm

  • 300g (30 per box, NEQ: 9.0kg) - cartridge length: 372mm

Suitable for:

  • Low-height benching blasts

  • Hard embedded rock blasting

  • Very large oversize management

  • Tunneling blasts

  • Trenching blasts

Standard Cartridge assembled with ignitor

Optional assembly to accommodate a detonator/shocktube initiation

Product is fully accredited in all major global markets including:

  • CE mark of approval (European Union);

  • USA (Department of Transport)

  • Canada (Ministry of Natural Resources)

  • South Africa (SAPS) and continental Africa

  • Australia (Chamber of Mines)

  • India (Explosive regulator)

  • Continental South America (Brazil, Chile, Mexico)

AutoStem Generation 2 - 43mm cartridge suitable for a hole size up to 50mm

AUTOSTEM PYROTECHNIC

SAFE DEMOLITION WITH NO VIBRATIONS OR SHOCKWAVE

Building demolition can be safely conducted using the AutoStem (Generation 1) Cartridge. The Cartridge offers the advantage of being user-friendly in built-up areas and is effective in the safe bringing down of multiple story buildings. Without generating a shockwave, AutoStem Cartridges can be used in nearby vicinities of windows and sensitive structures without causing any damage.

AN ENVIRONMENTALLY RESPONSIBLE SOLUTION

TO UNDERWATER BLASTING

AutoStem (Generation 1) Cartridge is also waterproof, meaning under water blasting can be done up to a depth of 10m, making AutoStem the safest and least environmentally impactful product available today. No harm to sea life, immediate diver re-entry and no clearing area or port down - time required.

LOW VIBRATION, MORE CONTROL

AutoStem Technology
